SPECIFICATIONS
| Height Accuracy (standard deviation for 1km double run leveling) | Digital Reading | 0.3mm |
| Optical Reading | 2.0mm | |
| Distance Accuracy | Digital Reading | D≤10m:10mm; D>10m:D*0.001 |
| Distance Range | Digital Reading | 2m~110m |
| Minimum Display | HD | 0.01mm/ 0.1mm/ 1mm |
| Distance | 0.1/ 1cm | |
| Measuring Time | within 3s in normal condition | |
| Telescope | Magnification | 32X |
| Resolving Power | 3″ | |
| Field of View | 1°30′ | |
| Multiple Constant | 100 | |
| Additive Constant | 0 | |
| Compensator | Type | magnetic-damped |
| Range | >±12′ | |
| Accuracy | 0.20″/ 1′ | |
| Data Storage | Storage | 128MB |
| Point Name | increasing/ decreasing/ customized | |
| Connection | RS232/ Bluetooth | |
| External Storage | U disk | |
| Circular vial Accuracy | 8’/ 2mm | |
| Display | 3.0 inch LCD Colorful Touch Screen | |
| Working Temperature | -20°C ~ 50°C | |
| Dimension | 230mm X 225mm X 203mm | |
| Weight | 3.1kg | |
| IP Standard | IP65 |
Note: all information above is subject to change without any prior notice.
